Epson Surepress L-4033 AW
First InstallationNovember 2016
Year of manufacture2016
Print-TechnologyEpson Micro Piezo Inkjet-Technology
Number of Heads15 Micro Piezo Printheads
Ink TypeWater-Based pigment ink
Ink Drop Sizevariable up to 3 picoliters minimum size
ColoursCyan | Magenta | Yellow | Black or Black matte | Orange | Green | WHITE
Resolutionup to 720 x 1.440 dpi
Web Width80 mm to 330.2mm | adjustable to support any width in this range
Image Sizemax 315,2 mm x 914,4 mm
Printing Speedup to 5 m/min
SubstratesStandard self-adhesive label stock and film (no pre-coating required!), Semi-gloss, gloss and matte paper stock, BOPP, PET and Yupo
Substrate thickness100 to 320 microns
Unwinder Capacity600 mm
HardwareEpson Control PC
Press DimensionsW 379 cm D 185 cm H 202 cm
Rewinder DimensionsW 131 cm D 90 cm H 100 cm
Required Floor SpaceW 510 cm D 300 cm
Power RequirementsInput voltage range: Rated voltage ± 10% (180-220V). Rated voltage AC (3 phases 3 lines) 220 V
Description
"Your affordable entry into the lucrative label market". The Epson SurePress L-4033AW digital label printing machine with 7-colour inkjet technology makes the flexible printing of high-quality labels easier and more efficient. The Epson SurePress L-4033AW delivers exceptional print quality and accurate color reproduction on a variety of standard label substrates. Commercial printers and label makers can use
this machine to expand the breadth of their offerings and improve their profitability. The Epson SurePress AQ Ink offers excellent adhesion to standard substrates for labels. Pretreatment or coating is not required!
The inspection and cleaning of the printheads is automated and the ink cartridges can be changed without stopping the machine. Both increase the available production time.
